Details

---

Product Description

The JBL SLP12/T is a sleek, low-profile on-wall loudspeaker that delivers superior sound and wide, consistent coverage. Featuring a powerful 75mm (3-inch) full-range driver, it ensures the legendary JBL sound in a compact design. With a 15-watt multi-tap transformer for 70V/100V systems and switchable 8Ω direct operation, it’s highly versatile for various installations.

Ideal for restaurants, hotels, resorts, retail outlets, and classrooms, the SLP12/T combines elegant industrial design with professional-grade performance. Its 15° down-tilted coverage ensures optimal sound projection while mounting flush to the wall. Easy installation, weather-resistant protection, and award-winning design make it the perfect solution for modern spaces.

✅ Key Features

• 75 mm (3 in) full-range transducer

• 40W continuous pink noise / 80W program power handling

• 15° down-tilted coverage for wall-mounted applications

• Slide-in wall bracket for quick installation

• Weather-resistant terminal rain cover included

• Multi-tap transformer for 70V/100V operation

• Ultra-slim design (ADA compliant, less than 4 in deep)

• Available in black or white finishes

⚙️ Technical Specifications

• Frequency Range (-10 dB): 74 Hz – 20 kHz

• Frequency Response (±3 dB): 91 Hz – 18 kHz

• Power Rating: 40W continuous pink noise / 80W program

• Sensitivity: 84 dB (half-space, wall-mounted)

• Maximum SPL (1m): 100 dB continuous / 106 dB peak

• Coverage Angle: 120°H × 120°V

• Nominal Impedance: 8Ω

• Transformer Taps: 70V (15/7.5/3.8/1.9W), 100V (15/7.5/3.8W)

• Driver: 75 mm (3 in) full-range polypropylene cone

• Enclosure Material: Polycarbonate + ABS, UL94V-0 flame rated

• Dimensions (H × W × D): 230 × 248 × 100 mm

• Net Weight: 1.9 kg

• Included Accessories: Wall-mount bracket, Euroblock connector, rain cover
